83Instrument cluster
Technical
data
Instruments
and controls
Operation Driving
Instrument
cluster display
Practical hints Car care Index
1 Push buttons V and W for intensity of instrument
lamps, see page 85
2 Push button J for resetting trip odometer, see
page 87, or to acknowledge a malfunction or
warning message, see page 104.
3 Coolant temperature gauge, see page 86
4 Fuel gauge with reserve and fuel cap placement
warning lamp, see page 230
5 Outside temperature indicator, see page 86
6 Left turn signal indicator lamp, see combination
switch on page 117
7 ESP warning lamp, see page 231
8 Speedometer
9 Trip odometer, see page 87
10 Main odometer
11 Multifunction indicator, see page 88
or FSS indicator, see page 109
or engine oil level indicator, see page 112
12 Right turn signal indicator lamp, see combination
switch on page 117
13 Tachometer, see page 87
14 Gear range indicator display, see selector lever
positions on page 198
15 Clock, see page 106
