90-830234R3 DECEMBER 1997 POWERHEAD - 4-67
3 Cylinder Manual Start Harness Routing
a
b
c
d
a - Stator Harness
b - Trigger Harness
c - RPM Limiter Harness
d - Overheat Sensor Lead
