27PAGE
8 OHM
Partial back view of amplifier
SERIES BOX
8 Ohm
4 Ohm
4 Ohm
4 OHM
8 OHM
Partial back view of amplifier
PARALLEL BOX
8 Ohm
16 Ohm
16 Ohm
16 Ohm Cabinet
16 Ohm Cabinet
4 OHM
WIRING SCHEMES...Amplifier to Speaker Cabinets
CORRECT
MATCH
CORRECT
MATCH
76
4 Ohm Cabinet
4 Ohm Cabinet
5
8 Ohm Cabinet
16 Ohm Cabinet
4 OHM 8 OHM
Partial back view of amplifier
SAFE MISMATCH
NOTE:BothSeriesandParallelboxesmaybepurchasedthroughMesa/BoogiebycontactingCustomerService:707-778-6565,Mon-Thurs9am-5pmPST
