Meyer Sound UltraCompact High-Power Curvilinear Array Loudspeaker M'elodie User Manual

35
APPENDIX C
26.48
[672.52 mm]
28.54
[724.84 mm]
12.75
[323.85 mm]
9.19
[233.31 mm]
7.08
[179.91 mm]
6.30
[160.02 mm]
4.10
[104.14 mm]
PHYSICAL
Enclosure Premium birch plywood
Finish Black textured
Protective grille Powder-coated, hex-stamped steel, black mesh
Rigging QuickFly rigging with four captive GuideALinks in the bottom corners of two aluminum and
steel end frames, secured with quick-release pins
Dimensions 28.54 w x 9.19 h x 12.75 d (724.84 mm x 233.31 mm x 323.85 mm)
Weight Weight 62 lbs (28.12 kg)
