Specifications
Page 6
Outdoor coil
Number of rows 1
Tube pitch(a)x row pitch(b) mm 21x22
Fin spacing mm 1.2
Fin type (code) Hydrophilic aluminum
Tube outside dia.and type mm Φ7,Inner groove tube
Coil length x height x width mm 870x504x22
Number of circuits 2
Outdoor air flow m3/h 2000
Outdoor sound pressure level dB(A) 55.5
Outdoor sound power level dB(A) 63
Outdoor unit
Dimension(W*D*H) mm 800x333x554
Packing (W*D*H) mm 920x390x615
Net/Gross weight Kg 29.3/32.1
Refrigerant
Type R32
GWP 675
Charged quantity Kg 0.69
Design pressure MPa 4.3/1.7
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ9.52(1/4"/3/8")
Max. refrigerant pipe length m 25
Max. difference in level m 10
Connection wiring 1.0x5Core
Plug type no-plug
Thermostat type Remote Control
Operation temperature 17-30
Ambient tempera-
ture
Indoor(cooling/ heating) °C 17-32/0-30
Outdoor(cooling/heating) °C -15-50/-25-30
Qty’per 20’ /40’ /40’HQ 84/174/205
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB Heating: - Indoor Temperature 20°C(68°F) DB / 15°C(59°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB -Outdoor Temperature 7°C(44.6°F) DB / 6°C(42.8°F) WB
-Interconnecting Piping Length 5m - Interconnecting Piping Length 5 m
- Level Difference of Zero. - Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
