8 TIMER Button:
This button is used to preset the time ON (start to operate) and the time OFF (turn off the operation)
9 ON/OFF Button:
Push this button to start the unit operation. Push the button again to stop the unit operation.
10 FAN Speed Button:
This button is used for setting fan speed in the sequence that goes from AUTO, LOW, MED to HIGH, and then
back to Auto.
11 TEMP UP Button:
Push this button to increase the indoor temperature setting or to adjust the timer in a counter-clockwise direction.
12 VENT Button:
Push this button to set the ventilating mode. The ventilating mode will operate in the following sequence:
Note: Ventilation Function is available for the Fresh Star Series.
13.1.3 Introduction of Indicators
1 TRANSMISSION Indicator:
This indicator lights when remote controller transmits signals to indoor unit.
2 MODE Display:
Shows the current operation mode - AUTO, COOL, DRY or HEAT. HEAT only available for heat pump model.
3 HEAT PUMP ONLY- LOCK display
Thi function is displayed by pushing the LOCK button. Push the LOCK button again to clear display.
4 TIMER Display:
This display area shows the settings of TIMER. That is, if only the starting time of operation is set, it will display the
TIMER ON. If only the turning off time of operation is set, it will display the TIMER OFF. If both operations are set, it
will show TIMER ON OFF which indicates you have chosen to set both the starting time and off time.
5 FAN Display:
When the FAN button is pushed, this signal indicator lights.
6 Digital Display Area:
This area will show the temperature, and if in the TIMER mode, it will show the ON and OFF settings of the TIMER.
Note: All items are shown in the Fig for the purpose of clear presentation, But during the actual operation only the relati ve functional items are
shown on the display panel.
13.1.4 Operational Guidelines
1 Install / Replace Batteries
The Remote Controller uses two alkaline dry batteries(R03/Ir03×2).
1) To install batteries, slide back the cover of the battery compartment and install the batteries according to the
directions (+and -) shown on the Remote Controller.
2) To replace the old batteries , use the same method as mentioned above.
Continuous Auto Off
Display Panel
AUTO
COOL
DRY
HEAT
1 6
2
3 4
5
FAN
HIGH
MED
LOW
