Midea C Series User Manual

AC Fan Coil Unit Two-pipe Wall-
mounted Series
- 6 -
MKG-500-B / MKG-600-B
Model MKG-500-B MKG-600-B
Power supply V/Ph/Hz 220-240/1/50
Air flow (H/M/L)
m3/h 850/745/620 1020/915/780
CFM 500/440/365 600/540/460
Cooling
Capac ity (H/M/L) kW 4.25/3.85/3.32 5/4.47/3.97
Water flow rate L/h 731 860
Water pressure drop kPa 31.8 42.5
Heating
Capac ity (H/M/L) kW 5.81/5.17/4.43 6.7/6/5.28
Water pressure drop kPa 30.2 39.7
Power input W 50 66
Current input A 0.22 0.29
Sound pressure level dB(A) 39/33/28 40/34/29
Fan motor
Type Low noise 4-speed fan motor
Quantity 1
Fan
Type Tangential fan
Quantity 1
Coil
Row 2
Diameter mm Φ7
Tube pitch(a) × row pitch(b) mm 21×13.37
Dimension (W×H×D) mm 785×315×26.74
Fin spacing mm 1.5
Fin type Hydrophilic aluminum
Circuit 5
Max. working pressure MPa 1.6
Body
Net dimensions (W×H×D) mm 1072×315×230
Packing size (W×H×D) mm 1180×415×315
Net weight kg 15.8 15.8
Gross weight kg 19.4 19.4
Pipe
connections
Water inlet/outlet pipe inch G3/4
Drain pipe mm ODΦ20
Notes:
1. H: high fan speed; M: medium fan speed; L: low fan speed
2. Cooling Conditions: Entering Water 7°C, Temperature Rise 5°C, Entering Air Temperature 27°C DB,19°C WB.
Heating Conditions: Entering Water 50°C, Enter air temperature 20°C, and water flow is same to the cooling conditions.
3. Noise is tested in semi-anechoic test room.
