Midea MRS26D5AST User Manual

12
Refrigerator
Safety
Operating
Requirements
Parts and
Features
Installation
Refrigerator
Use
Refrigerator
Care
Troubleshooting
Before
Use
REMOVE DOORS
IMPORTANT: Keep the refrigerator doors closed until you are ready to lift
them from the cabinet.
1.
3.
2.
Using a Phillips screwdriver, remove the four screws attaching the
hinge cover to the top of the cabinet.
Hinge cover
Screws
4. Slowly lift the hinge cover, keeping the wire harnesses attached.
Remove the Freezer bottom hinge cover screws and hinge cover.
Pull out the locking washer from the water pipe connector and the pull out
the freezer door water pipe from quick connector.
Note: please be noted the fast connector can’t be left at the end of
water pipe of door.
5. Disconnect the wiring harnesses by pressing the release catch
on each wire harness connector, and then pulling the ends apart (left-
hand door hinge only).
Wiring harnesses

Midea MRS26D5AST Specifications

General

Style	Side-by-Side
Color	Stainless Steel
Number of Doors	2
Total Capacity	29.5 Cu. Ft.
Refrigerator Capacity	450 L
Freezer Capacity	250 L
Number of Refrigerator Shelves	5: Adjustable
Number of Refrigerator Bins	1 small) and Dairy Corner
Humidity Controlled Crispers	1
Number of Freezer Shelves/Baskets	-
Refrigerator Temperature	34/44 °F
Refrigerator Special Features	Internal Water Dispenser
Freezer Special Features	Power Freeze Option
Defrost System	Automatic
Noise level	43 dB
Refrigerant	-
Energy Class	-
Annual Energy Consumption	715 kWh
Voltage	115 V
Frequency	60Hz
Current	-

Weight and Dimensions

Depth	742 mm
Height	70 1/8 in
Width	1000 mm
Net Weight	-
