Service Manual_2017-V1
12
7.Remove the two hole caps from the left side, where the
center hinge will go,and insert them into the other
side.Attach the refrigerator door on the bottom hinge,
then attach the center left hinge to the left side of the
refrigerator.the top hinge and replace the hinge cover.
8.Put the freezer door onto the center left hinge, then
attach the top left hinge to the top of refrigerator. Cover
the hinge with the top left hinge cover and cover the
screw
holes on the right side of the top with the cover plate you
previously removed.
9.Remove the screw caps on the door handles, then
remove the four Allen-screws securing
the handles to the left side of the doors with the Allen
wrench. Remove the handles.
10.Remove the four Phillips-head screws from the left
side of the door.Screw the four Phillips-head screws into
the holes on the right side of the door.Attach the handles
to the right sides of doors with the Allen-head screws you
just removed. Tighten with the Allen wrench and replace
the screw caps.
