The hoses can be connected at an
angle to suit the installation.
Tip to make fitting easier:
Moisten the
hose seals with water or suds solution
beforehand.
^
Press each hose using some force
into its appropriate opening and
secure to the dispensing unit with the
screws supplied.
Attaching the plug connector
The connection socket for the plug
connector is located at the rear of the
washing machine.
^ Lift up the retainer and pull the cap
off the connection socket.
^
Plug in the connector and close the
retainer to secure it in place.
,
If the plug connector is removed,
it must be replaced with the cap.
Make sure the cap is secured by the
retainer.
Installation and connection
10
