Installation
Make sure power is not supplied to
the appliance while installation or
maintenance work is performed.
Disconnect the power supply to the
work area by unplugging the unit,
tripping the circuit breaker or
removing the fuse. The coffee
system must be installed into
cabinetry before being used.
^ Unscrew the height adjustable feet
on the underside of the machine
about 1/16" (2 mm).
^
Push the appliance all the way back
into the cabinet and center it. If
necessary level the unit with the four
height adjustable feet.
The feet can be turned out up to 3/8"
(10 mm).
^
If your cabinet has 3/4" (19 mm) side
walls, drill four holes for the
mounting.
^
Center the unit and turn the screws a
little bit in and then out again.
^
Take the unit out of the niche and drill
four holes at the screw markings
(1/16" [2 mm], diameter 3/16"
[4.5 mm]).
^
Plug the appliance into the electrical
outlet.
^
Push the appliance into the niche.
^
Open the door and partially tighten
the screws.
^
Carefully turn the lower screws, a,to
center the machine.
^
To secure the appliance in the
cabinet, tighten the upper screws, b,
by hand. Do not use an electric
screwdriver.
Installation
59
