Miele DAS 2620 User Manual

Operation
17
Switching the fan on
Switch the fan on as soon as you start
cooking. This is to ensure that vapours
are captured right from the start.
 Pull out the deflector plate. To ensure
optimum extraction and a low noise
level, pull the canopy all the way out.
The fan will switch on at power level 2.
Selecting a power level
For light to heavy cooking vapours and
odours, select from power levels 1 to 3.
For short periods of cooking food with
intensive vapours and a strong aroma,
e.g. when searing meat, select Booster
settingB.
 Select the power level you want by
pressing the  or  controls.
Reducing power down from the
Booster setting
If Power management is activated
(default setting), the fan automatically
switches back to level 3 after 5minutes.
Run-on time
 It is advisable to run the fan for a few
minutes after cooking has finished.
This helps to remove any lingering
vapours and odours from the air.
It also reduces the risk of residues
accumulating in the rangehood and any
resultant odours.
Switching the fan off
 Turn off the fan by pushing the
deflector plate back in. The next time
the deflector plate is pulled out, the
range hood will switch on at setting 2
again.
 Press the On/Off touch control  to
switch the fan off.
Switching the cooktop lighting
on/off
The cooktop lighting can be switched
on and off independently of the fan.
 You can switch the cooktop lighting
on and off by pulling the deflector
plate out and pushing it in or by
pressing the lighting control .
The  symbol will light up when the
cooktop lighting is switched on.

Miele DAS 2620 Specifications

General

Noise level	61 dB
Pressure (Pa)	422
Intensive speed	Yes
Number of speeds	3
Type of extraction	Ducted/Recirculating
Noise level (low speed)	47 dB
Maximum extraction power	559 m³/h
Noise level (medium speed)	55 dB
Maximum recirculating power	550 m³/h
Minimum distance from gas hob	650 mm
Noise level (intensive speed)	68 dB
Fluid dynamic efficiency class	A
Minimum distance from electric hob	450 mm
Current	10 A
Connected load	200 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Annual energy consumption	41.7 kWh
Bulb type	LED
Bulb power	3.2 W
Illuminance	310 lx
Number of bulbs	1 bulb(s)
Type	Built-in
Cord length	1.5 m
Control type	Buttons
Product color	Stainless steel
Built-in display	No
Exhaust location	Top
Exhaust connection diameter	150 mm
Number of filters	1 pc(s)

Weight and Dimensions

Width	596 mm
Weight	12000 g
Depth (max)	423 mm
Depth (min)	273 mm
Height (max)	436 mm
