Technical Information
8
DG 408x Steam Ovens
Figure D-2: Overview of DG 4082 (Front View)
1
Control panel
2
Door release
3
Air vent
4
Door seal
5
Steam channel
6
Steam generator compartment
7
Steam generator (with insert)
8
Steam generator electrical connection
9
Runners
10
Steam port
11
Drip channel
12
Floor heater
13
Temperature sensor
14
Air vent
