Technical Information
G600 & G800 Electronic Dishwashers
5.21 Flow-Through Heater - Removal
Refer to figure 5-19.
1. Remove the Left Side Panel (5.3).
2. Fold up the insulation – as needed.
Figure 5-19: Dishwasher with Flow-Through Heater
3. Disconnect the Electrical Connections.
4. Disconnect the Top and Bottom Hose Connections (Items 1&4).
5. Lift upwards on the Flow-Through Heater Assembly to release it
from the Retainer (Item 2).
Service Tip
When replacing a Flow-Through Heater, the old Seal should be
replaced with a new part. See Figure 5-20 – Item 1.
73
