Technical Information
20
PW 6xx7
060 Drive
1 Technical Data
Model Drive moto
Power transmission
PW 6107 3-phase 2200W Drive belt 10PJ 1752
PW 6137 3-phase 2200W Drive belt 10PJ 1752
PW 6167 3-phase 2500W Drive belt 12PJ 2083
PW 6207 3-phase 4300W Drive belt 12PJ 2083
Table 060-1: Drive Motor Data
Note:
Measurement is to be carried out in accordance with the
manufacturer’s instructions on the measuring instrument. Take care
with the dimensional units of the measuring instrument. There are
still measuring scales in kg (effectively kilopond/newton)! Conversion
factors: 1 kp = 9.80665 N, 1 N = 0.102 kp. A mass of 1 kg exerts a
weight force of almost 1 kp on the earth.
The measurement is taken in the middle of the free-hanging belt span.
After installing and tensioning a new drive belt, allow it to operate and
turn at least 3 times (approximately 15 minutes) before taking the
measurement.
Model Tension of a new Hutchinson 10PJ 1752 drive belt
During installation
fter running-in (approx. 15
minutes operation)
Tension Frequency Tension Frequency
Krikit2 (tension gauge) Krikit2 (tension gauge)
PW 6107 / PW 6137 45 to 50 kg 105 to 110 Hz 35 to 40 kg 90 to 98 Hz
Table 060-2: Tension of a New Hutchinson 10PJ 1752 Drive Belt
Note:
Measurement is to be carried out in accordance with the
manufacturer’s instructions on the measuring instrument. Take care
with the dimensional units of the measuring instrument. There are
still measuring scales in kg (effectively kilopond/newton)! Conversion
factors: 1 kp = 9.80665 N, 1 N = 0.102 kp. A mass of 1 kg exerts a
weight force of almost 1 kp on the earth.
The measurement is taken in the middle of the free-hanging belt span.
To avoid damage, do not tension a drive belt that has been in use for
some time with the same high tension as a new drive belt.
Model Tension of a Hutchinson 10PJ 1752 drive belt after it has been in
use for a long period (more than 1 week)
Retension from Retension to Maximum
Tension Frequency Tension Frequency
Krikit2 (tension gauge) Krikit2 (tension gauge)
PW 6107 / PW 6137 < 25kg < 80Hz to 35kg to 90Hz
Table 060-3: Tension of a Hutchinson 10PJ 1752 Drive Belt in Use
