Technical Information
93
PW 6xx7
Service mode (service level)
1 Service program
1 Test manually
1 System analysis
2 Control-power module (component) (ELP 235)
3 Selection-display module (control element) (EW 235)
4 Frequency converter (modulator) (EFU 235)
5 Multifunction module 1 (ELZ 235)
6 Multifunction module 2 (ELZ 235)
7 Multifunction module 3 (ELZ 235)
8 Card reader module
9 Operating data module
10 Load module
11 MPG (German medical product law) module
12 Language
Table 100-45: Test Manually Subdivisions
When the desired item has been selected via the multifunction selector, press
the OK button. The selected service program then starts immediately and can
be stopped when the Back button is pressed.
Note:
All service programs are limited to an overriding safety time of 30 minutes.
System analyze has the following subdivisions:
Service mode (service level)
1 Service programs
1 Test manually
1 System analysis
Designation Display Explanation
-
e.g., Analysis in
progress
Checks all modules and their
sensors to see if they are present.
Checks checksums (tests sums to
verify integrity of data and
programs) of operating system,
wash programs, languages, etc.
Table 100-46: System Analyze
If no fault is registered by the system analysis, Function available is
displayed. For specific details on fault information, see the appropriate
function.
When the desired item has been selected via the multifunction selector, press
the OK button. The selected service program then starts immediately and can
be stopped when the Back button is pressed.
Control-power module has the following subdivisions:
Service mode (service level)
1 Service programs
1 Test manually
2 Control-power module (component)
Designation Display Explanation
Machine type:
e.g., PW 6107 electric
heating
Display of model registered by the control
with type of heating
Heating type
ID number e.g., 123456789
Display of ELP 235 power module ID
number registered by the control
Door
Door open/closed/
locked/unlocked symbol.
Control indicates state of door contact
switch
