Technical Information
97
PW 6xx7
be stopped when the Back button is pressed.
Load module (module for automatic load registration) has the following
subdivisions:
Service mode (service level)
1 Service programs
1 Test manually
10 Load module
Designation Display Explanation
Calibration Press 0 kg or 25 kg button To set automatic weighing process
Test Insert test weight
Weighing function constantly displays
registered drum load.
Table 100-53: Load Module
MPG (German medical product law) module has no function or test points.
Service mode (service level)
1 Service programs
1 Test manually
11 MPG (German Medical Product Law) module
Designation Display Explanation
--- --- ---
Table 100-54: MPG Module
Language module has no function or test points.
Service mode (service level)
1 Service programs
1 Test manually
13 Language module
Designation Display Explanation
--- --- ---
Table 100-55: Language Module
When Test automatically is selected, the automatic test starts with a system
analysis. If a fault is registered, the automatic test stops. It can then be quit
by pressing the Back button or continued by pressing the OK button.
Service mode (service level)
1 Service program
2 Test automatically
1 System analysis
Selection-display module (EW 235)
Control-power module (ELP 235)
All modules
NTCs
System check
2 Door Door contact switch
3 Control elements
Multifunction selector
All buttons
4 Display Display
5 Tachogenerator check Tachogenerator signal registration
6 Drive check without water Drive motor
7 Minimum heating level Valves, analog pressure sensor
8 Checking of all water valves Water valves
9 Drive check with water
Drive, tachogenerator, frequency converter,
analog pressure sensor
10
Software for overflow level (420
mm wc)
Drain valve seal
Drain function
11 Water intake to 150 mm wc
Heating at full power to raise temperature by 5ºC
Drain valve
Spin speed
Deceleration
Table 100-56: Test Automatically
