4G9 ENGINE (E-W) -
Intake Manifold (GDI)
11A-6a-2
PWEE9502-D
E
Jun. 1998Mitsubishi Motors Corporation Added
REMOVAL AND INSTALLATION <For SPACE RUNNER>
11 Nm
19 Nm
9Nm
8
10
1
9
5
6
7
3
2
4
11 Nm
11 Nm
9Nm
19 Nm
Removal steps
1. Air by-pass hose
2. Vacuum pipe and hose
3. Bracket
4. Solenoid valve
5. Connector bracket
6. Accelerator cable bracket
7. Vacuum hose
8. Vacuum pipe
9. Intake manifold
10. Intake manifold gasket
