3
6) Remote commands (Not executable in stand-by mode. When the remote commands are sent while the splash
screen is being displayed, the splash screen is only canceled.)
Some remote control operations can be achieved by the remote command codes. The remote commands have no
data codes.
[Example] When displaying the MENU selection bar. (Figures and symbols enclosed in quotation marks are
ASCII codes.):
7) Password lock commands
The password lock commands control the password lock. The password lock enabling or disabling command is sent
with a 4 to 8-digit password comprised of any figures 1 to 4 added to the end of the data code. When the password
lock is enabled or disabled successfully, the projector sends a return command comprising the data code, password,
and “1” at the end. When enabling or disabling the password lock fails, it sends a return command with “0” at the
end. There is no reconfirmation of the password. The password input command is for enabling projection of image
when password lock has been set to DISPLAY INPUT. The password input command is sent with a 4 to 8-digit pass-
word comprised of any fi gures 1 to 4 at the end.
**** is a 4 to 8-digit password comprised of any figures 1 to 4.
[Example] When enabling the password lock of DISPLAY INPUT (in the case that the password is 123412). (Fig-
ures and symbols enclosed in quotation marks are ASCII codes.):
Button’s name on remote ASCII HEX Button’s name on remote ASCII HEX
S r53 72h 35h 33h AV MEMORY 2 re5 72h 65h 35h
T r2b 72h 32h 62h AV MEMORY 3 re6 72h 65h 36h
W r4f 72h 34h 66h CONTRAST rd0 72h 64h 30h
X r59 72h 35h 39h BRIGHTNESS rd1 72h 64h 31h
MENU r54 72h 35h 34h COLOR TEMP. rd4 72h 64h 34h
ENTER r10 72h 31h 30h GAMMA rd5 72h 64h 35h
AUTO POSITION r09 72h 30h 39h SHARPNESS rd6 72h 64h 36h
ASPECT re2 72h 65h 32h COLOR rd2 72h 64h 32h
AV MEMORY 1 re4 72h 65h 34h COLOR MANEAGEMENT rb4 72h 62h 34h
Sending commands
from the PC, etc.
Status code
from the projector
Description
30 30 72 35 34 0D
‘0’ ‘0’ ‘r’ ‘5’ ‘4’ ‘ ’
Command operating the same as the
MENU button
30 30 72 35 34 0D
‘0’ ‘0’ ‘r’ ‘5’ ‘4’ ‘ ’
Command receipt confirmation
(Command echo back)
ITEM ASCII HEX VALUE
Password lock enabling/
disabling
PSLOCK 50h 53h 4Ch 4Fh 43h 4Bh 0**** (Disabling), 1**** (DISPLAY INPUT),
2**** (MENU ACCESS)
Password input PASS 50h 41h 53h 53h ****
Sending commands
from the PC, etc.
Status code
from the projector
Description
30 30 50 53 4C 4F 43 4B 31 31 32 33 34 31 32 0D
‘0’ ‘0’ ‘P’ ‘S’ ‘L’ ‘O’ ‘C’ ‘K’ ‘1’ ‘1’ ‘2’ ‘3’ ‘4’ ‘1’ ‘2’ ‘ ’
Command for enabling the password
lock of DISPLAY INPUT
30 30 50 53 4C 4F 43 4B 31 31 32 33 34 31 32 31 0D
‘0’ ‘0’ ‘P’ ‘S’ ‘L’ ‘O’ ‘C’ ‘K’ ‘1’ ‘1’ ‘2’ ‘3’ ‘4’ ‘1’ ‘2’ ‘1’ ‘ ’
Response informing that the
projector succeeded in enabling the
password lock of DISPLAY INPUT
To Next Page
