Motorola 56F8323 User Manual

2-16 56F8323EVM User Manual MOTOROLA
27 NC 28 NC
29 NC 30 NC
31 GND 32 GND
33 GND 34 GND
35 NC 36 NC
37 NC 38 NC
39 NC 40 NC
41 NC 42 NC
43 GND 44 GND
45 NC 46 NC
47 NC 48 NC
49 NC 50 NC
51 NC 52 GND
53 GND 54 GND
55 +3.3V 56 +3.3V
57 GND 58 GND
59 +5.0V 60 +5.0V
Table 2-10. Memory Daughter Card Connector Description (Continued)
J2
Pin # Signal Pin # Signal
