Motorola APX 6000 Service Manual

7-14 Troubleshooting Tables: List of Board and IC Signals
Table 7-10. EXPANSION board to AVR / JTAG Interface PIN-OUT
Test Place
Expansion Board
AVR / JTAG
signal name
pin #
chassis GND J2001-1
none USB1_DM J2001-2
none USB1_DP J2001-3
none AVR_TCK J2001-4
R2026 AVR_MACE_TDO J2001-5
R2028 AVR_MACE_TDI J2001-6
R2030 AVR_MACE_TMS J2001-7
none BT_AVR_RESET_3.3V J2001-8
R2450 USB_BOOT_1.8V J2001-9
TP2005 VCC_1.85 J2001-10
R2493 GPS_BT_3.3V J2001-11
R2444 AVR_USART2_RX J2001-12
none AVR_USART2_TX J2001-13
chassis GND J2001-14
none VBUS1 J2001-15
none MACE_TCK J2001-16
none MACE_RTCK J2001-17
none MACE_NTRST J2001-18
none BT_HCI_RX J2001-19
none BT_HCI_TX J2001-20
TP2404 BT_TX_DBG J2001-21
chassis GND J2001-22

Motorola APX 6000 Specifications

General

Frequency Range	700/800 MHz, VHF, UHF Range 1, UHF Range 2
IP Rating	IP67
P25 Phase 1 & 2	Yes
GPS	Yes
Encryption	AES, DES
Power Output	1-3 Watts (700/800 MHz)
Operating Temperature	-30°C to +60°C
Intrinsically Safe	Yes
Bluetooth	Yes (Bluetooth 4.0)
