Motorola CDM1250 Service Manual

Radio Model Information Section 1: 1-3
6881091C63-F
2.5 Technical Support
Motorola provides technical support to assist dealers, distributors and self-maintained customers in
resolving problems, if any, with their unit. When contacting Motorola Technical Support, keep the
radio’s model number and the unit’s serial number handy. Technical support contact information is
listed below.
3.0 Radio Model Information
The radio’s model number and serial number are located on a label attached to the back of the unit.
The radio’s model number indicates the unit’s RF output power, frequency band, protocols, and
physical packages. The example below shows a mobile radio model number and its characteristics.
Table 1-1 Radio Model Number (Example: AAM25KHC9AA1AN)
United States and Puerto Rico: 1-800-927-2744
Mexico, Caribbean, South and Central America: Go to https://www.motorola.com/businessonline.
Log in and click on Contact Us.
Motorola
Internal
Use Only
Type of
Unit
Model
Series
Freq. Band
Power
Level
Physical
Packages
Channel
Spacing
Protocol
Feature
Level
Model
Revision
Model
Package
AA
or
LA
M
(for
Mobile)
25 K
VHF
(136–174
MHz)
H
1–25W
C
No Display,
Basic
Keypad
9
Program-
mable
AA
Conven-
tional
1
4F
AN
B
Low Band, R1
(29.7–36.0
MHz)
K
25–40
W
A
No Display
No Keypad
DU
LTR
2
64F
C
Low Band, R2
(36.0–42.0
MHz)
D
1-Line
Display,
Limited
Keypad
DP
PassPort
and LTR
5
128F
D
Low Band, R3
(42.0–50.0
MHz)
F
1-Line
Display,
Standard
Keypad
PW
1.5ppm
6
160F
LTR
R
UHF1
(403–470
MHz)
8
160F
S
UHF2
(CDM:450–
512 MHz,
PRO,1–25 W:
450-527 MHz,
PRO,25–40
W:450-520
MHz

Motorola CDM1250 Specifications

General

Display	Alphanumeric
IP Rating	IP54
Frequency Range	VHF: 136-174 MHz, UHF: 403-470 MHz
Signaling	PL, DPL, MDC1200, Quick Call II
Operating Temperature	-22°F to +140°F (-30°C to +60°C)
Power Output	VHF: 1-25W; UHF: 1-25W
