5-14
MS-7176 ATX Mainboard
RAID Migration Instructions
The Intel Matrix Storage Console offers the flexibility to upgrade from a single
Serial ATA (SATA) hard drive to RAID configuration when an additional SATA hard
drive is added to the system. This process will create a new RAID volume from an
existing disk. However, several important steps must be followed at the time the
system is first configured in order to take advantage of RAID when upgrading to a
second SATA hard drive:
1. BIOS must be configured for RAID before installing Windows XP on the
single SATA hard drive. Refer to On Chip SATA Setting for properly
setting of the BIOS.
2. Install the Intel Application Accelerator RAID Driver during Windows Setup.
Refer to Installing Software for instructions on installing the driver
during Windows Setup.
3. Install the Intel Matrix Storage Console after the operating system is installed.
To create a volume from an existing disk, complete the following steps:
After the Intel Matrix Storage Console has been successfully installed and
the system has rebooted, click on the Intel Application Accelerator shortcut link (Start
--> All Programs --> Intel Matrix Storage Manager --> Intel Matrix Storage
Console) and the following window will appear:
MSI Reminds You...
A Create from Existing Disk operation will delete all existing data
from the added disk and the data cannot be recovered. It is critical to
backup all important data on the added disk before proceeding. However,
during the migration process, the data on the source disk is preserved.
