Chapter 1

Important

Do not touch the CPU socket pns.

Con󰘰rm that the CPU cooler has formed a tght seal wth the CPU before bootng

your system.

Whenever the CPU s not nstalled, always protect the CPU socket pns by coverng

the socket wth the plastc cap.

Please refer to the documentaton n the CPU cooler package for more detals about

CPU cooler nstallaton.

•

Push down on the heatsnk untl the

four clps get wedged nto the holes

on the manboard. Press the four

hooks down to fasten the cooler. As

each hook locks nto poston a clck

should be heard.

9. Inspect the manboard to ensure that

the clp-ends have been properly

locked n place.

10.

Fnally, attach the CPU fan cable

to the CPU fan connector on the

manboard.

11.

Manboard

Hook
