VGA Port
The DB15-pn female connector s provded for montor.
HDMI Port (optonal)
The Hgh-De󰘰nton Multmeda Interface (HDMI) s an all-dgtal audo/vdeo nterface
capable of transmttng uncompressed streams. HDMI supports all TV format, ncludng
standard, enhanced, or hgh-de󰘰nton vdeo, plus mult-channel dgtal audo on a sngle
cable.
DVI Port (optonal)
The DVI (Dgtal Vsual Interface) connector allows you to connect a LCD montor. It
provdes a hgh-speed dgtal nterconnecton between the computer and ts dsplay
devce. To connect an LCD montor, smply plug your montor cable nto the DVI
connector, and make sure that the other end of the cable s properly connected to your
montor (refer to your montor manual for more nformaton.)
Important
The VGA, HDMI and DVI dsplay nterfaces on the manboard are desgned to serve
as IGP (Integrated Graphcs Processor) used. If you nstalled a processor wthout
ntegrated graphcs chp, these dsplay ports wll have no e󰘯ect.
Audo Ports
These audo connectors are used for audo devces. It s easy to d󰘯erentate between
audo e󰘯ects accordng to the color of audo jacks.
Lne-In: Blue - Lne In, s used for external CD player, tape-player or other audo
devces.
Lne-Out: Green - Lne Out, s a connector for speakers or headphones.
Mc: Pnk - Mc, s a connector for mcrophones.
RS-Out: Black (optonal) - Rear-Surround Out n 4/ 5.1/ 7.1 channel mode.
CS-Out: Orange (optonal)- Center/ Subwoofer Out n 5.1/ 7.1 channel mode.
SS-Out: Gray (optonal)- Sde-Surround Out 7.1 channel mode.
Important
To reach the 8-channel sound e󰘯ect, the 7th and 8th channels must be output from front
panel f you purchase the manboard wth 3 audo jacks.
▶
▶
▶
▶
■
■
■
■
■
■
