MSI MAG Z590 TOMAHAWK WIFI User Manual

32
Overview of Components
Component Contents
Port Name Port Type Page
CPU_FAN1, PUMP_FAN1,
SYS_FAN1~6
Fan Connectors 44
CPU_PWR1~2, ATX_PWR1,
PCIE_PWR1
Power Connectors 41
CPU Socket LGA1200 CPU Socket 33
DIMM Slots Memory slots 34
JAUD1 Front Audio Connector 35
JBAT1 Clear CMOS (Reset BIOS) Jumper 46
JCI1 Chassis Intrusion Connector 45
JDASH1 Tuning Controller connector 40
JFP1, JFP2 Front Panel Connectors 40
JRAINBOW1~2 Addressable RGB LED connectors 48
JRGB1~2 RGB LED connector 47
JTBT1 Thunderbolt Add-on Card Connector 46
JTPM1 TPM Module Connector 43
JUSB1~2 USB 2.0 Connectors 43
JUSB3 USB 3.2 Gen 1 Connector 42
JUSB4 USB 3.2 Gen 2 Type-C Connector 42
LED_SW1 EZ LED Control 49
M2_1~3 M.2 Slots (Key M) 36
PCI_E1~4 PCIe Expansion Slots 35
SATA1~6 SATA 6Gb/s Connectors 39

MSI MAG Z590 TOMAHAWK WIFI Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Audio chip	Realtek ALC4080
Component for	PC
Motherboard chipset	Intel Z590
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 x64
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2666, 2933, 3200, 4000, 4400, 4700, 5333 MHz
Number of M.2 (M) slots	3
PCI Express x1 (Gen 3.x) slots	2
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way CrossFireX
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
LAN controller	Intel I225-V
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax)
Bluetooth version	5.2
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN controller model	Intel Wi-Fi 6E AX210
Ethernet interface type	2.5 Gigabit Ethernet
Number of SATA II connectors	0
Number of SATA III connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	1
BIOS type	UEFI AMI
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	244 mm
Width	305 mm
