CHAPTER 2
HARDW
ARE INST
ALLA
TION
2-7
A. How to install a DIMM Module
1. The DIMM slot has 2 Notch Keys “VOL
T and DRAM”, so the
DIMM memory module can only fit in one direction.
2. Insert the DIMM memory module vertically into the DIMM slot.
Then push it in.
3. The plastic clip at the side of the DIMM slot will automatically
close.
Single Sided DIMM
Double Sided DIMM
VOL
T
DRAM
2.3-2 Memory Installation Procedures
