Chapter 1
Important
Do not touch the CPU socket pns.
Con󰘰rm that the CPU cooler has formed a tght seal wth the CPU before bootng
your syste.
Whenever the CPU s not nstalled, always protect the CPU socket pns by coverng
the socket wth the plastc cap.
Please refer to the documentaton n the CPU cooler package for more detals about
CPU cooler nstallaton.
•
•
•
•
Push down on the heatsnk untl the
four clps get wedged nto the holes
on the manboard. Press the four
hooks down to fasten the cooler. As
each hook locks nto poston a clck
should be heard.
9. Inspect the manboard to ensure that
the clp-ends have been properly
locked n place.
10.
Fnally, attach the CPU fan cable
to the CPU fan connector on the
manboard.
11.
Manboard
Hook
