3. Install the receiver
See paragraph 4.3 of the building instructions.
4. Assemble the model
See paragraph 5 of the building instructions and Fig. 33.
5. Set the correct control surface travels and Centre of Gravity
See paragraphs 7 and 8 of the building instructions and Fig. 34.
6. Go ying with the EasyGlider 4
See paragraphs 9 and 10 of the building instructions and Figs. 35 - 40.
Parts List RR EasyGlider 4
No. Quantity Description
1 1 EasyGlider 4 building instructions
2 1 Complaint processing form
3 1 Fuselage with servos and power set
4 1 L.H. wing with servo
5 1 R.H. wing with servo
6 1 Tailplane
7 1 Fin
8 1 M5 plastic screw
9 1 Allen key, 1.5 mm A/F
10 1 Hook-and-loop tape, hook
11 1 Hook-and-loop tape, loop
12 1 Foam block battery retainer
Essential / recommended accessories:
Airborne radio control system components / other accessories
MULTIPLEX receiver RX-5 light M-Link Order No. 5 5808
or MULTIPLEX receiver RX-5 M-Link (telemetry capable) Order No. 5 5817
2x servo Tiny-S (elevator/rudder) Order No. 6 5121
2x servo Nano-S (aileron) Order No. 6 5120
2x Servo extension lead 300mm Order No. 8 5031
2x Servo extension lead 150mm Order No. 8 5019
Power set
Power set „EasyGlider 4“ Order No. 33 2672
with ROXXY C28-34-850kv brushless motor and
ROXXY BL-Control 720 S-BEC speed controller
Battery
LiPo ROXXY EVO 3-2200 20C (M6) Order No. 31 6655
Adhesives
Zacki ELAPOR® 20g Order No. 59 2727
Zacki ELAPOR® Super liquid 10g Order No. 59 2728
Hot-melt adhesive
Battery charger
12V/230V Power Peak B6 Order No. 30 8561
Tools required
Balsa knife, side-cutters, screwdrivers (for M3 and M5 slot-head screw, and M2.5 cross-point screw), pliers, 13 mm A/F spanner,
320-grit abrasive paper, hot-melt glue gun.
