19
GB
# 21 4228
Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely hope that you
are completely satisfied with the contents of your kit. However, we would ask you to check all the parts before you start
construction, referring to the Parts List, as we cannot exchange components which you have already modified. If you find any
part is not acceptable for any reason, we will readily correct or exchange it once we have examined the faulty component. Just
send the component to our Model Department. Please be sure to include the purchase receipt and a brief description of the fault.
We are constantly working on improving our models, and for this reason we must reserve the right to change the kit contents in
terms of shape or dimensions of parts, technology, materials and fittings, without prior notification. Please understand that we
cannot entertain claims against us if the kit contents do not agree in every respect with the instructions and the illustrations.
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings. Building and operating them safely
requires a certain level of technical competence and manual skill, together with discipline and a responsible attitude at the
flying field. Errors and carelessness in building and flying the model can result in serious personal injury and damage to
property. Since we, as manufacturers, have no control over the construction, maintenance and operation of our products,
we are obliged to take this opportunity to point out these hazards and to emphasise your personal responsibility.
Additional items required for the MENTOR:
Receiving system components in the model
MULTIPLEX RX-7-Synth IPD receiver 35 MHz A-band Order No. 5 5880
alternatively: 40 / 41 MHz band Order No. 5 5882
or MULTIPLEX RX-9 Synth DS IPD receiver 35 MHz A-band Order No. 5 5885
2 x MULTIPLEX Mini HD servo (elevator / rudder) Order No. 6 5123
2 x MULTIPLEX Tiny MG servo (ailerons) Order No. 6 5122
1 x MULTIPLEX Tiny MG servo (aero-tow release) Order No. 6 5122
Power set:
MULTIPLEX Magister / Mentor power set Order No. 33 2632
Motor: Himax C 3528-1000, speed controller: CC PHOENIX 45, propeller: 11 x 5.5”, driver and spinner
Flight battery:
MULTIPLEX Li-Batt BX 3/1-3200 flight battery Order No. 15 7136
or MULTIPLEX Li-Batt BX 3/1-4800 flight battery Order No. 15 7150
Tools:
Scissors, balsa knife, combination pliers, screwdriver.
Specification:
Wingspan 1630 mm
Fuselage length 1170 mm
All-up weight with Li-Batt BX 3/1-3200 approx. 2000 g
Wing area approx. 45 dm²
Wing loading (FAI) approx. 44.5 g / dm²
RC functions Aileron, elevator, rudder and motor; optional aero-tow release
Note: please remove the illustration pages from the centre of the instructions.
Important note
This model is not made of styrofoam™, and it is not possible to glue the material using white glue, polyurethane or
epoxy; these adhesives only produce a superficial bond which gives way when stressed. Please use medium-
viscosity cyano-acrylate glue exclusively, preferably our Zacki-ELAPOR®, # 59 2727 - the cyano glue optimised
specifically for ELAPOR® particle foam.
If you use Zacki-ELAPOR® you will find that you do not need cyano kicker or activator for most joints. However, if
you wish to use a different adhesive, and are therefore obliged to use kicker / activator spray, we recommend that
you apply the material in the open air to avoid health problems.
Please take care when handling cyano-acrylate adhesives. These materials harden in seconds, so you should
avoid getting them on your fingers or other parts of the body. We strongly recommend the use of goggles to protect
your eyes. Keep the adhesive out of the reach of children.
