natus ALGO 5 Service Manual

10 ALGO® 5 Newborn Hearing Screener Service Manual
P/N 000976 Rev.A
Red Transducer:
right ear
Blue Transducer:
left ear
Connector
FIGURE 5: Acoustic Transducer Assembly (ATA 5)
FIGURE 6: Patient Cable Assembly (PCA 5)
Connecto
r
Na
p
e - White
Common - Green
Vertex - Black

natus ALGO 5 Specifications

General

Technology	AABR
Data Storage	USB
Connectivity	USB
Power	AC power or battery
Frequency Range	500 – 4000 Hz
Display	7” color LCD touch screen
