NETGEAR NIGHTHAWK AX12 User Manual

Your Preset Wireless Settings
WiFi Network Name (SSID):
Network Key (Password):
Your Preset Wireless Settings
WiFi Network Name (SSID):
Network Key (Password):
Do More With the Nighthawk App
Now that your Nighthawk WiFi is set up, here are some more
things you can do with the app:
View a list of devices that are connected to your
network.
Change your WiFi network name and password.
Test your router’s Internet connection speeds.
Router
Power adapter
(varies by region)
Ethernet cable
Package Contents
Router WiFi Network Name and Password
A sticker on your router displays the preset WiFi network name,
password, and QR code.
Example
Rear Panel
1
LED On/Off switch
2
Ethernet ports 1–4
Note: Ethernet ports 1 and
2 can be used for Ethernet
port aggregation.
3
Internet port
1
2
3
4
5
6
7
8
4
Multi‑Gig Ethernet port
5
Reset button
6
USB ports 1 and 2
7
Power On/Off button
8
DC Power connector

NETGEAR NIGHTHAWK AX12 Specifications

General

Product type	Tabletop router
On/off switch	Yes
Product color	Black
LED indicators	LAN, Power, USB, WAN, WLAN
Processor cores	4
Processor frequency	2200 MHz
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Memory card slot(s)	No
Ethernet LAN (RJ-45) ports	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Cables included	LAN (RJ-45)
Antennas quantity	8
WAN connection type	RJ-45
Modulation	1024-QAM
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	6000 Mbit/s
Power source type	DC
Package depth	330 mm
Package width	249 mm
Package height	141 mm
Package weight	2320 g
Master (outer) case width	289 mm
Master (outer) case height	387 mm
Master (outer) case length	369 mm
Master (outer) case weight	6080 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	2 pc(s)
Mobile network generation	-
Browser supported	Internet Explorer 11, Microsoft Edge, Chrome 55, Firefox 45, Safari 10
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows XP
Supported network protocols	IPv6

Weight and Dimensions

Depth	70 mm
Width	310 mm
Height	28.5 mm
Weight	1364 g
