NETGEAR Orbi RBK23 User Manual

Package Contents
Orbi Router Overview
1
2
3
4
5
6
7
Orbi Satellite Overview
1
2
4
5
6
7
Orbi Router
(Model RBR20)
Orbi Satellites (2)
(Model RBS20)
Ethernet cable
Power adapters (3)
(vary by region)
1
Ring LED (not shown in image)
2
Sync button (also used for WPS
connection)
3
Internet port (the satellite does not
include an Internet port)
4
Ethernet ports
5
Power On/Off button and
Power LED
6
Power connector
7
Reset button

NETGEAR Orbi RBK23 Specifications

General

Type	Network transmitter & receiver
Package type	Box
Cables included	LAN (RJ-45)
AC adapter included	Yes
Number of products included	3 pc(s)
Output current	1.5 A
Output voltage	12 V
Power source type	AC
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
DSL WAN	No
Modulation	256-QAM
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	WPA, WPA-PSK
WLAN data transfer rate (first band)	866 Mbit/s
WLAN data transfer rate (third band)	400 Mbit/s
Ethernet LAN (RJ-45) ports	2
Antennas quantity	4
Processor frequency	710 MHz
Product type	Tabletop router
Product color	White
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	61 mm
Width	142.24 mm
Height	167.64 mm
Weight	476.27 g
