NETGEAR Orbi RBK753 User Manual

Your settings are saved.
Manage network access control lists
You can use access control to block or allow access to your network.
To manage devices that are allowed or blocked:
1.
Launch a web browser from a computer or mobile device that is connected to your
Orbi network.
2. Enter orbilogin.com.
A login window opens.
3. Enter the admin user name and password.
The user name is admin. The password is the one that you specified the first time
that you logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Security > Access Control.
The Access Control page displays.
5. Select the Turn on Access Control check box.
6.
Click the View list of allowed devices not currently connected to the network
link.
The list displays.
7.
Select the check box for a device.
8.
Use the Add button, Edit button, and Remove from the list button as needed.
9. Click the Apply button.
Your settings are saved.
Schedule when to block Internet sites and
services
When you schedule blocking, the same schedule is used to block sites and to block
services. For information about how to specify what you want the router to block, see
Use
keywords to block Internet sites on page 41 and Avoid blocking on a trusted
computer on page 43.
User Manual45Control Access to the Internet
Orbi Whole Home Tri-Band Mesh WiFi 6 System

NETGEAR Orbi RBK753 Specifications

General

Model	RBK753
Type	Mesh WiFi System
WiFi Technology	WiFi 6 (802.11ax)
Coverage	Up to 7, 500 sq. ft.
Number of Units	3 (1 Router + 2 Satellites)
Compatibility	Works with any internet service provider
MU-MIMO	Yes
Beamforming	Yes
Frequency Band	2.4GHz, 5GHz
USB Port	No
Processor	Quad-Core 1.4 GHz
Memory	512MB NAND Flash and 512MB RAM
Security	WPA2/WPA3
Parental Controls	Circle Smart Parental Controls
Antenna Type	Internal
Dimensions (Router)	9.1 x 7.2 x 2.8 inches
Dimensions (Satellite)	9.1 x 7.2 x 2.8 inches
