NEUTON CE5.4 Battery-Powered Mower -
Safety & Operating Instructions
13
Neuton CE5.4 Product Specifications
Motor
RPM 4300
Tip Speed 16,000 ft./min.
AMP Idle 4 – 5
AMP Cutting 8 – 10
Size 500W, 24V DC/32 Amp
Noise Under 80 Decibels
Controls
Start/Stop Safety Control Lever(s), Start and Stop
Shape Comfortable, Ergonomically Designed Housing
User Interface Battery Voltage Level Indicator
Housing
Material Injected Polypropylene
Handlebar Height Adjustment 34.6" – 37.5" (at lowest Housing height)
Wheels, Front 7" x 1.6", Molded Rubber Tread
Wheels, Rear 8" x 1.9", Molded Rubber Tread
Weight 50 lbs. (including Battery)
35 lbs. (without Battery)
Housing Length 30"
Housing Width 18"
Housing Height 12.5"
Cutting
Cutting Deck Width 14.2
Blade 14" Steel Aero Blade (extra Blades available)
Mulching Blade optional
Blade Nut Torque 16.6 ft-lbs.
Blade Function Cutting and Mulching
Cutting Height Easily Adjustable from 1.2 – 3.0 inches
Discharge Rear Discharge Chute (sold separately)
Bagger Rear Bagger Included
Bagger Capacity 1 Bushel (1.26 cubic ft.)
Mulching Mulching Plug Included
Trimming Optional Trimmer/Edger Attachment
Lawn Size Up to 1/4 acre on a single Battery charge
Battery
Voltage 24V DC
AMP 10 Amp-Hour
Type Sealed, Lead/Acid
Weight 15 lbs. 5 oz.
Approximate Run Time 45 - 60 minutes for fully charged Battery
Battery Charger Included. 24V Charger, plugs into standard electrical outlet
Charge Time 8-14 Hours
Replacement Easy to lift out and replace with optional spare Battery
Optional Accessories
Trimmer Plug-in Trimmer/Edger w/2 extra spools
Trimmer Cord 80 MIL/2.0mm Diameter x 14.6 Feet/Spool
Blade Sharpener Hand-Held Sharpener
Protective Cover Fits machine with Handlebars up or down
Rear Side Discharge Chute Attaches to back of Mower
Spare Battery 24V DC, 10 Amp-Hour
Spare Cutting Blade
Meets CPSC Mower Safety Standards
Lever Position Cut Height
1 1.2" (30 mm)
2 1.5" (38 mm)
3 1.9" (47 mm)
4 2.2" (56 mm)
5 2.6" (65 mm)
6 3.0" (75 mm)
