INTRODUCTION
FintypeWavy
Finpitch1.75mm(0.06890in)
Intercooler
FintypeWavy
Finpitch2.5mm(0.09843in)
Fuelcooler
FintypeWavy
Finpitch2.0mm(0.07874in)
Uppersideworksystem
Type
Backhoeattachment
Components,dimensions,workingdimensions
StandardbucketcapacityHeaped1.60m³(56.5ft³)(Leveled1.17m³(41.3ft³)
Bucketwidth
1450mm(57.1in)
Bucketwidthwithsidecutter
1564mm(61.6in)
Bucketweightwithsidecutter
1590kg(3505.3lb)
Boomlength
6450mm(253.9in)
Armtype
Standard(STD/HD)3.25m
(10.663ft)
Short(STD/HD)2.63m
(8.629ft)
Armlength
3250mm(127.953in)2630mm(103.543in)
Bucketradius
1680mm(66.142in)
Bucketwristangle
173°
Maximumdiggingradius
11170mm(439.764in)10670mm(420.079in)
Maximumdiggingradiusatgroundline
10980mm(432.28in)10470mm(412.20in)
Maximumdiggingdepth
7340mm(288.976in)6730mm(264.961in)
Maximumverticalstraightwalldiggingdepth
6350mm(250.000in)5970mm(235.039in)
Maximumdiggingheight
10370mm(408.268in)10320mm(406.299in)
Maximumdumpheight
7230mm(284.646in)7140mm(281.102in)
Minimumswingradiusatfront4500mm(177.165in)4630mm(182.283in)
Heightforminimumswingradiusatfront8480mm(333.858in)8540mm(336.220in)
Operatingdevice
Operator’sseat
Position
Leftside
StructureAdjustableforward,back,upanddown,reclining
mechanism,withseatsuspension
CabSealedsteel,type,allreinforcedglass,withsunroof
Leversandpedals
Fortraveluse
Leverandpedaltype(hydraulicpilottype)x2
Foroperatingmachineuse
Levertype(hydraulicpilottype)x2
Instrumentsandswitches
Workmodeswitchover
3modes(SP/H/A)
Travelmodeswitchover
Low-speed/high-speedswitchtype
One-touchidle
Knobswitchtype
Engineemergencystop
Switchtype
Monitordevice
Machinestatusdisplay(TFTcolorliquidcrystal)
Messagedisplay
Workmodeselectstatus
SP/H/A
Instruments
Fuelgauge
Enginecoolanttemperaturegauge
Hydraulicoiltemperaturegauge
Hourmeter
4802496828/07/2016
17
