INTRODUCTION
Workingrange
SMIL16MEX1412FB2
(A)Maximumdiggingreach6150mm(242.1in)
(A’)Maximumdiggingreachonground6010mm(236.6in)
(B)Maximumdiggingdepth3570mm(140.6in)
(B’)Maximumdiggingdepth(8ftlevel)3160mm(124.4in)
(C)Maximumverticalwalldiggingdepth3040mm(119.7in)
(D)Maximumdiggingheight5680mm(223.6in)
(E)Maximumdumpingheight3930mm(154.7in)
(F)Minimumswingradius2420mm(95.3in)
Boomswingradius(left-hand/right-hand)
G=2.4m(8.0ft)
70°/50°
SAE
36.6kN(8228.0lb)
Bucketdiggingforce
ISO
40.9kN(9194.7lb)
SAE
25.6kN(5755.1lb)
Armcrowdforce
ISO
26.5kN(5957.4lb)
Monoboomwithboomswingsystem:2.9m(114.173in)
