Nikon D3300 User Manual

307Technical Notes
Viewfinder
eyepiece
accessories
• DK-5 Eyepiece Cap (0 73): Prevents light entering via the
viewfinder from appearing in the photograph or
interfering with exposure.
• DK-20C Eyepiece Correction Lenses: Lenses are available with
diopters of –5, –4, –3, –2, 0, +0.5, +1, +2, and +3 m
–1
when
the camera diopter adjustment control is in the neutral
position (–1 m
–1
). Use eyepiece correction lenses only if
the desired focus can not be achieved with the built in
diopter adjustment control (–1.7 to +0.5 m
–1
). Test
eyepiece correction lenses before purchase to ensure that
the desired focus can be achieved.
The rubber eyecup
can not be used with eyepiece correction lenses.
• Magnifier DG-2: The DG-2 magnifies the scene displayed in
the center of the viewfinder for greater precision during
focusing.
Eyepiece adapter required (available
separately).
• Eyepiece Adapter DK-22: The DK-22 is used when attaching
the DG-2 magnifier.
• Right-Angle Viewing Attachment DR-6: The DR-6 attaches at a
right angle to the viewfinder eyepiece, allowing the
image in the viewfinder to be viewed at right angles to
the lens (for example, from directly above when the
camera is horizontal).
Software
• Capture NX 2: A complete photo editing package offering
such features as white balance adjustment and color
control points.
Note: Use the latest versions of Nikon software.
Most Nikon
software offers an auto update feature (Nikon Message
Center 2) when the computer is connected to the Internet.
See the websites listed on page xviii for the latest
information on supported operating systems.

Nikon D3300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6000 x 4000 pixels
Still image resolution(s)	4800 x 1080, 1632 x 4800, 9600 x 1080, 1632 x 9600, 4496 x 3000, 2992 x 2000
Optical zoom	- x
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto
Auto Focus (AF) lock	Yes
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted
ISO sensitivity	100, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Flash off, Flash on
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	PCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	921000 pixels
Magnification	0.85 x
USB version	2.0
HDMI connector type	Mini
Scene modes	Children, Close-up (macro), Night portrait, Sports, Landscape (scenery)
Image editing	Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Fluorescent, Incandescent, Shade
Shooting modes	Scene
Camera playback	Movie, Single image
Self-timer delay	2, 5, 10, 20 s
Languages support	ARA, BUL, CHI (SIMPL), CHI (TR), DAN, DEU, DUT, ENG, FIN, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SER, SWE, THA, TUR, UKR
Camera file system	RAW
Battery type	EL14a
Number of batteries supported	1
Product color	Red
Storage temperature (T-T)	0 - 85 °C
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	98 mm
Width	124 mm
Height	75.5 mm
Weight	410 g
Weight (including battery)	460 g
