Nikon D600 User Manual

237
U
❚❚ Commander Mode
Use the built-in flash as a master flash controlling one or more remote optional flash
units in up to two groups (A and B) using advanced wireless lighting (0 294).
Selecting this option displays the menu shown at right.
Press 4
or 2 to highlight the following options, 1 or 3 to change.
A The SB-400
When an optional SB-400 flash unit is attached and turned on, Custom Setting e3 changes to
Optional flash, allowing the flash control mode for the SB-400 to be selected from TTL and
Manual (Repeating flash and Commander mode options are not available).
A “Times“
The options available for Repeating Flash > Times are determined by flash output.
Output Options available for “Times” Output Options available for “Times”
1/4 2 1/32 2–10, 15
1/8 2–5 1/64 2–10, 15, 20, 25
1/16 2–10 1/128 2–10, 15, 20, 25, 30, 35
Option Description
Built-in
flash
Choose a flash mode for the built-in flash (commander flash).
TTL
i-TTL mode. Choose flash compensation from values between +3.0 and –3.0 EV in
increments of
1
/3 EV.
M Choose the flash level from values between 1/1 and 1/128 (
1
/128 of full power).
––
The built-in flash does not fire, although remote flash units do. The built-in flash
must be raised so that it can emit monitor pre-flashes.
Group A Choose a flash mode for all flash units in group A.
TTL
i-TTL mode. Choose flash compensation from values between +3.0 and –3.0 EV in
increments of
1
/3 EV.
AA
Auto aperture (available only with compatible flash units; 0 294). Choose flash
compensation from values between +3.0 and –3.0 EV in increments of
1
/3 EV.
M Choose the flash level from values between 1/1 and 1/128 (
1
/128 of full power).
–– The flash units in this group do not fire.
Group B
Choose a flash mode for all flash units in group B. The options available are the
same as those listed for Group A, above.
Channel
Choose from channels 1–4. All flash units in both groups must be set to the same
channel.

Nikon D600 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Full-frame
Image stabilizer	Yes
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	4512 x 3008 3008 x 2008 3936 x 2624 2944 x 1968 1968 x 1312
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Selective Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	50, 100, 200, 400, 800, 1600, 3200, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	50
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Flash exposure correction	-3EV - +1EV (1/2; 1/3 EV step)
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Second display	No
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
USB version	2.0
HDMI connector type	Mini
Power source type	AC, Battery
Product color	Black
Eye relief	20.6 mm
Scene modes	Beach, Candlelight, Children, Close-up (macro), Cuisine, Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Rotating
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Battery life (CIPA standard)	900 shots
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
