Nikon D600 User Manual

64
y
A HDMI
If the camera is connected to an HDMI device (0 204), the
view through the lens will appear both in the camera monitor
and on the HDMI device. The indicators that appear in the
HDMI device during movie recording are shown at right. The
camera monitor does not show the sound level or virtual
horizon; indicators in the monitor and on the HDMI device
can not be hidden or displayed using the R button. To use
live view when the camera is connected to an HDMI-CEC device, select Off for HDMI >
Device control in the setup menu (0 205).
A Remote Cords
If Record movies is selected for Custom Setting g4 (Assign shutter button, 0 248), the
shutter-release buttons on optional MC-DC2 remote cords (0 298) can be used to start
movie live view and to start and end movie recording.
D Recording Movies
Flicker, banding, or distortion may be visible in the monitor and in the final movie under
fluorescent, mercury vapor, or sodium lamps or if the camera is panned horizontally or an
object moves at high speed through frame (for information on reducing flicker and banding,
see Flicker reduction, 0 252). Jagged edges, color fringing, moiré, and bright spots may
also appear. Bright bands may appear in some areas of the frame with flashing signs and
other intermittent light sources or if the subject is briefly illuminated by a strobe or other
bright, momentary light source. When recording movies, avoid pointing the camera at the
sun or other strong light sources. Failure to observe this precaution could result in damage
to the camera’s internal circuitry. Note that noise (randomly-spaced bright pixels, fog, or
lines) and unexpected colors may appear if you zoom in on the view through the lens (0 55)
during movie live view.
Flash lighting can not be used during movie live view.
Recording ends automatically if the lens is removed, the mode dial is rotated, or a remote
control release mode is selected.
Live view may end automatically to prevent damage to the camera’s internal circuits; exit live
view when the camera is not in use.
Note that the temperature of the camera’s internal
circuits may rise and noise (bright spots, randomly-spaced bright pixels, or fog) may be
displayed in the following instances (the camera may also become noticeably warm, but this
does not indicate a malfunction):
• The ambient temperature is high
• The camera has been used for extended periods in live view or to record movies
• The camera has been used in continuous release mode for extended periods
If live view does not start when you press the a button, wait for the internal circuits to cool
and then try again.

Nikon D600 Specifications

General

Megapixel	24.3 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Full-frame
Image stabilizer	Yes
Total megapixels	24.7 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Maximum image resolution	6016 x 4016 pixels
Image sensor size (W x H)	35.9 x 24 mm
Still image resolution(s)	4512 x 3008 3008 x 2008 3936 x 2624 2944 x 1968 1968 x 1312
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Selective Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	50, 100, 200, 400, 800, 1600, 3200, 6400, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	50
Light exposure correction	±5EV (1/2; 1/3 EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	0.005 s
Flash exposure correction	-3EV - +1EV (1/2; 1/3 EV step)
Video resolutions	1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Resolution at capture speed	1280x720@25fps, 1280x720@50fps, 1280x720@60fps, 1920x1080@24fps, 1920x1080@25fps, 1920x1080@30fps
Audio formats supported	LPCM
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Second display	No
Display diagonal	3.2 \
Display resolution (numeric)	921000 pixels
Magnification	0.7 x
USB version	2.0
HDMI connector type	Mini
Power source type	AC, Battery
Product color	Black
Eye relief	20.6 mm
Scene modes	Beach, Candlelight, Children, Close-up (macro), Cuisine, Dawn, Dusk, Night landscape, Night portrait, Party (indoor), Portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Rotating
Photo effects	Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Shade, Sunny
Shooting modes	Aperture priority, Auto, Manual, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3
Diopter adjustment (D-D)	-3 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL15
Battery life (CIPA standard)	900 shots
Operating temperature (T-T)	0 - 40 °C
Cables included	USB

Weight and Dimensions

Depth	82 mm
Width	141 mm
Height	113 mm
Weight	760 g
Weight (including battery)	850 g
