3 Getting Started
26 Nikon N Series/K Series Total Station Instruction Manual
Changing Regional Configuration Pre-sets
To provide easier configuration for common regional settings, you can quickly
configure the Nikon total station to a pre-set combination of default regional settings.
The Regional Configuration screen appears only after the language configuration is
complete, the instrument has rebooted, and the telescope has been tilted. To change
the regional configuration pre-sets:
1. Follow the steps in Selecting a Language, page 25.
Once the instrument reboots and the
telescope is tilted, the Regional
Configuration screen appears.
2. Press
[^] or [v] to highlight the required
regional settings and then press
[ENT].
3. If you do not want to change the current
settings, press
[ESC] and quit. The instrument will continue to use the last
configured settings that were configured.
The settings affected by the Regional Configuration screen are:
Category Setting Europe International United States
Angle VA zero Zenith Zenith Zenith
Resolution 1"(See note) 1"(See note) 1"(See note)
HA Azimuth Azimuth Azimuth
Distance Scale 1.000000 1.000000 1.000000
T-P corr. On On On
Sea Level Off Off Off
C&R corr. 0.132 0.132 0.132
Coordinates Order ENZ ENZ NEZ
Label ENZ ENZ NEZ
AZ zero North North North
Power Save Main Unit Off Off Off
Sleep 5 minutes 5 minutes 5 minutes
Communication Ext. Comm Nikon Nikon Nikon
Baud 4800 4800 4800
Length 8 8 8
Parity None None None
Stop bit 1 1 1
Stakeout Add PT 1000 1000 1000
Units Angle GON DEG DEG
Distance meters meters US-ft
Temp °C °C °F
Press mm Hg mm Hg In Hg
Rec Store DB RAW&XYZ RAW&XYZ RAW&XYZ
Data Rec Internal Internal Internal
