Tube Diameter (mm) 25.4 25.4 25.4 25.4
(in) 1 1 1 1
Objective Outside Diameter (mm) 47.3 58.7 39.3 39.3
(in) 1.86 2.31 1.55 1.55
Length (mm) 312 325 248 248
(in) 12.3 12.8 11.2 11.2
Weight (g) 388 470 354 340
(oz) 13.7 16.6 12.5 12.0
Adjustment Graduation* :1 click :1 click :1 click :1 click
(moa)
Max Internal*
Adjustment (moa) 80 80 80 80
(Elevation & Windage)
Parallax Setting (m) 91.44 91.44 68.58 45.72
(at factory) (yards) 100 100 75 50
Outside Diameter of (mm) 39.3 39.3 39.3 39.3
Eyepiece (in) 1.55 1.55 1.55 1.55
*moa= minute of angle
** (at minimum magnification)-(at maximum magnification)
: At 100 yards :At 75 yards :At 50 yards
3. Instructions
(1) Focusing
• Look through the eyepiece with your eye positioned about 10cm (4 in)
away from the eyepiece lens (Fig. 3-1), and you will see the Nikoplex
reticle (Fig. 3-2), or the BDC reticle (Fig. 3-3).
• Be sure your eye is positioned within proper alignment and proper eye
relief otherwise the view will “black out.”
• Point the objective end of the scope at the sky (Do not point at the sun) or
at a plain unpatterned wall.
• Loosen the lock ring.
• Turn the eyepiece adjustment counter-clockwise and then turn it
clockwise until the reticle appears sharp.
• Finally, without moving the eyepiece adjustment, turn the eyepiece lock
ring as Fig. 3-4 to end so that the eyepiece adjustment will be firmly
locked.
The lock ring must be firmly tightened to ensure an air-tight seal.
(2) Magnification
• The riflescope 4x32 has a fixed magnification of 4X.
