Niles AC-3 User Manual

AUTOMATED SWITCHING SYSTEMS
NILES AUDIO CORPORA
TION
12331 S.W
. 130 Str
eet, Miami, FL 33186 T
el: 800.259.4434 –
www
.nilesaudio.com
NAAC3PDF
FEATURES
■ Three AC outlets—two switched, one unswitched; 1,500W maximum (all outlets combined)
■ AC-3 is activated by 12Volt DC signal (100mA minimum)
■ Requires 12Volt DC adapter to trigger AC-3 from the switched outlet of a receiver or preamp,
can also be triggered by the 12volt output of a Niles APC-2, AC-3, SPK-1, SAS-1 or RFS-1
■ 12Volt control output for activating other Niles devices such as an APC-2, AC-3, SPK-1,
SAS-1 or RFS-1
S
PECIFICATIONS
■ Dimensions: 5-1/4" wide x 2-1/4" high x 4-1/4" deep
Warranty: Two-year limited
120Volt AC Power Switching System
AC-3
Stock Number
FG00242
Product Detail
Using the AC-3 to increase the wattage capacity of a switched outlet to 1500 watts.
IN OUT
+ – + –
LR
AC-3
PREAMP
AMP 1
AC CORD
SWITCHED
UNSWITCHED
AC CORD
WALL
OUTLET
15 AMP
LR
AMP 2
AC CORD
12V DC
OUT
PLUG INTO
SWITCHED OUTLET
(NOT INCLUDED)

Niles AC-3 Specifications

General

Brand	Niles
Model	AC-3
Category	Switch
Language	English
