Get started
12
the windshield. Ensure that you do not heat the windshield excessively to
avoid damage to it.
Press the suction cup firmly on the windshield, and carefully push the
locking lever above the suction cup towards the suction cup to create a
vacuum between the suction cup and the windshield (1). Check that the
suction cup is firmly attached. If you want to detach the mounting device
from the windshield, carefully push the locking lever toward the top of
the mounting device, and pull the strap located on the edge of the
suction cup.
To attach the mobile holder to the mounting device, insert the catches at
the top of the mounting device into the slots on the mobile holder (2), and
2
3
5
1
4
9200268_EN_SP_POB_FR.book Page 12 Friday, March 9, 2007 12:52 PM
