Nokia 6111 User Manual

Get started
Copyright © 2006 Nokia. All rights reserved. 14
7. Close the SIM card holder,
and press it down slightly.
8. To lock the SIM card holder, slide
it away from the compartment
lid (1).
9. Close the SIM card
compartment (2).
Install battery
Important: Always use
original Nokia batteries.
1. Open the cover of the connector
panel (1).
2. Press the red release button
above the connector panel (2),
and take off the back cover of the
phone (3).
3. Observe the battery contacts,
and place the battery in the
battery compartment.
4. Place the back cover in the
double catch of the phone (1) and
press it down slightly (2) to close
the back cover.
■ Charge the battery
Warning: Use only
batteries, chargers, and
enhancements approved by
Nokia for use with this
particular model. The use of
any other types may
invalidate any approval or
warranty, and may be
dangerous.
This device is intended for use when
supplied with power from an AC-3
charger.
For availability of approved
enhancements, please check with
your dealer.
Nokia_6111_China_UG_HKEN.fm Page 14 Thursday, October 25, 2007 2:54 PM

Nokia 6111 Specifications

General

Display Type	TFT, 256K colors
Display Size	1.8 inches
Resolution	128 x 160 pixels
Internal Memory	23 MB
Main Camera	1 MP
Battery Type	Removable Li-Ion 700 mAh battery (BL-4B)
Weight	92 g
Network Technology	GSM
2G bands	GSM 900 / 1800 / 1900
GPRS	Class 10
EDGE	Class 6
Announced	2005, June
Status	Discontinued
SIM	Mini-SIM
Pixel density	114 ppi
Video	yes
Alert types	Vibration; Downloadable polyphonic, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	No
WLAN	No
USB	Pop-Port
Messaging	SMS, MMS, Email, Instant Messaging
Browser	WAP 2.0/xHTML
Games	Yes + Downloadable
Java	Yes, MIDP 2.0
Stand-by	Up to 192 h
Dimensions	84 x 47 x 23 mm
Colors	Black, Silver, Pink
Radio	FM radio
