Oki MB451 User Manual

Basic Procedure for Faxing
-87-
Faxing (for MB451, MB451w, MB471, MB471w, MB491, ES4191 MFP only)
3
Using Transmission and Reception
History
You can select a destination from the 50 most
recent transmissions or receptions.
1 Press the to select [Tx History] or
[Rx History] and then press .
2 Press the to select an entry and then
press .
The check box is selected. You can select multiple
entries.
3 When you have selected all the
destinations, press the .
4 Check that [Complete] is selected and
then press .
Using One-Touch Key Pad
The one-touch key pad can hold fax numbers
registered in Speed Dial List.
The speed dials no.1 to 16 are automatically
registered to the one-touch key pad.
1 Press the desired one-touch key on the
start screen.
Press the <SHIFT> key to select the speed dials
no.9 to 16 assigned to the one-touch key pad.
Memo
 You can use the one-touch key pad also on the screen that
is displayed after pressing the <FAX/HOOK> key. In this
case, the fax standby screen appears after pressing a one-
touch key so that you can configure other advanced
settings for fax functions.
Deleting Specified Destinations
1 Select the specified destination on the
fax start screen by pressing and then
press .
2 Press the to select a destination you
want to delete and then press .
The check box is selected. You can select multiple
entries.
3 When you have selected all the
destinations to be deleted, press .
4 Check that [Delete The Address] is
selected and then press .
- If all recipients have been deleted, you will be
taken back automatically to the start screen.
- If not all recipients have been deleted, press to
go back to the start screen.
OK
OK
OK
OK
OK
OK

Oki MB451 Specifications

General

Duplex printing	Yes
Print technology	LED
Time to first page (black, normal)	5 s
Print speed (black, normal quality, A4/US Letter)	29 ppm
Dimensions (WxDxH)	455 x 425 x 427 mm
All-in-one functions	Copy, Fax, Print, Scan
Color all-in-one functions	No
Maximum duty cycle	30000 pages per month
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Time to first copy (black, normal)	11 s
Scan to	CIFS, Fax, FTP, USB
Grayscale levels	7
Scan speed (black)	37.5 ppm
Scan speed (color)	10 ppm
Image formats supported	BMP, GIF, JPG, PCX, PNG, TGA
Faxing	Mono faxing
Fax memory	200 pages
Modem speed	33.6 Kbit/s
Fax transmission speed	2 sec/page
Total input capacity	- sheets
Total output capacity	150 sheets
Maximum input capacity	350 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	9, 10, C5, C6, DL
Maximum print size	210 x 297 mm
Duplex media weight	60 - 112 g/m²
Paper tray media types	Envelopes
Paper tray media weight	60 - 120 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 150 g/m²
Display	LCD
Display resolution	320 x 128 pixels
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Security algorithms	SSL/TLS
Processor frequency	330 MHz
Sound power level (standby)	55 dB
Sound pressure level (quiet mode)	30 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	3 W
Power consumption (PowerSave)	14 W
Power consumption (average operating)	580 W
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	20 - 80 %
