Omron E2E User Manual

2 Inductive Sensors
DC 2-wire/Connector Models
Note: In addition to the above models, E2E-X@D15-M1G models (e.g., E2E-X3D15-M1G), which are different in frequency from the above models, are available.
DC 2-wire/Pre-wired Connector Models
*1. A model with no polarity has a residual voltage of 5 V, which must be taken into consideration together with the interface condition (the PLC’s ON voltage, for
example) when connecting the Proximity Sensor to a load.
*2. The standard cable length is 300 mm. Models are also available with 500 mm and 1 m cables.
Connector Pin Assignments of DC 2-wire Model
The connector pin assignments of each new E2E DC 2-wire conforms to IEC947-5-2 Table III.
The following E2E models with conventional connector pin assignments are available as well.
Connector Self-diagnostic
output function
Size Sensing
distance
Model
NO NC
M12 Yes Shielded M12 3 mm E2E-X3D1S-M1 ---
M18 7 mm E2E-X7D1S-M1 ---
M30 10 mm E2E-X10D1S-M1 ---
Unshielded M12 8 mm E2E-X8MD1S-M1 ---
M18 14 mm E2E-X14MD1S-M1 ---
M30 20 mm E2E-X20MD1S-M1 ---
No Shielded M8 2 mm E2E-X2D1-M1G E2E-X2D2-M1G
M12 3 mm E2E-X3D1-M1G (See note.) E2E-X3D2-M1G
M18 7 mm E2E-X7D1-M1G (See note.) E2E-X7D2-M1G
M30 10 mm E2E-X10D1-M1G (See note.) E2E-X10D2-M1G
Unshielded M8 4 mm E2E-X4MD1-M1G E2E-X4MD2-M1G
M12 8 mm E2E-X8MD1-M1G (See note.) E2E-X8MD2-M1G
M18 14 mm E2E-X14MD1-M1G (See note.) E2E-X14MD2-M1G
M30 20 mm E2E-X20MD1-M1G (See note.) E2E-X20MD2-M1G
M8 Shielded M8 2 mm E2E-X2D1-M3G E2E-X2D2-M3G
Unshielded 4 mm E2E-X4MD1-M3G E2E-X4MD2-M3G
Size Sensing distance Operation mode Polarity Model
Shielded M12 3 mm NO Yes E2E-X3D1-M1GJ
No E2E-X3D1-M1J-T
M18 7 mm Yes E2E-X7D1-M1GJ
No E2E-X7D1-M1J-T
M30 10 mm Yes E2E-X10D1-M1GJ
No E2E-X10D1-M1J-T
Unshielded M12 8 mm Yes E2E-X8MD1-M1GJ
M18 14 mm E2E-X14MD1-M1GJ
M30 20 mm E2E-X20MD1-M1GJ
Size Operation mode Model Size Operation mode Model
Shielded M8 NO E2E-X2D1-M1 Unshielded M8 NO E2E-X4MD1-M1
NC E2E-X2D2-M1 NC E2E-X4MD2-M1
M12 NO E2E-X3D1-M1 M12 NO E2E-X8MD1-M1
NC E2E-X3D2-M1 NC E2E-X8MD2-M1
M18 NO E2E-X7D1-M1 M18 NO E2E-X14MD1-M1
NC E2E-X7D2-M1 NC E2E-X14MD2-M1
M30 NO E2E-X10D1-M1 M30 NO E2E-X20MD1-M1
NC E2E-X10D2-M1 NC E2E-X20MD2-M1
