10-9
10 Operation
G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
10-3 Trial Operation
10
10-3-2 Test Operation via USB Communications from the CX-Drive
1 Use the Connector CN1.
2 Turn ON the Servo Drive power.
3 Connect a USB cable to the USB connector (CN7).
4 Start the CX-Drive and go online with the Servo Drive via USB communications.
5 Select Test Run from the Tu n i n g Menu of the CX-Drive.
6 Select Servo ON to servo-lock the Servomotor.
7 Select Forward or Reverse and start the Servomotor.
The Servomotor will rotate until Stop is selected.
Precautions for Correct UsePrecautions for Correct Use
The test operation function via USB communications from the CX-Drive cannot be used while
EtherCAT communications are established.
10-3-2 Test Operation via USB Communications from the CX-Drive
