2 Models and External Dimensions
2-14
G5-series AC Servomotors and Servo Drives User’s Manual (with Built-in EtherCAT Communications)
The tables in this section show the possible combinations of G5-series Servo Drives and Servomotors.
The Servomotors and Servo Drives can only be used in the listed combinations.
“-” at the end of the motor model number is for options, such as the shaft type, brake, oil seal and key.
* Use these combination with caution because the Servo Drive and Servomotor have different capacities.
2-3-3 Servo Drive and Servomotor Combination Tables
3,000-r/min Servomotors and Servo Drives
Voltage
Servomotor
Servo Drive
Rated
output
With incremental
encoder
With absolute
encoder
Single-phase
100 V
50 W R88M-K05030H- R88M-K05030T- R88D-KNA5L-ECT
100 W R88M-K10030L- R88M-K10030S- R88D-KN01L-ECT
Single-phase/
3-phase 100 V
200 W R88M-K20030L- R88M-K20030S- R88D-KN02L-ECT
400 W R88M-K40030L- R88M-K40030S- R88D-KN04L-ECT
Single-phase/
3-phase 200 V
*50 W R88M-K05030H- R88M-K05030T- R88D-KN01H-ECT
100 W R88M-K10030H- R88M-K10030T- R88D-KN01H-ECT
200 W R88M-K20030H- R88M-K20030T- R88D-KN02H-ECT
400 W R88M-K40030H- R88M-K40030T- R88D-KN04H-ECT
750 W R88M-K75030H- R88M-K75030T- R88D-KN08H-ECT
*1 kW R88M-K1K030H- R88M-K1K030T- R88D-KN15H-ECT
1.5 kW R88M-K1K530H- R88M-K1K530T- R88D-KN15H-ECT
3-phase 200 V 2 kW R88M-K2K030H- R88M-K2K030T- R88D-KN20H-ECT
3 kW R88M-K3K030H- R88M-K3K030T- R88D-KN30H-ECT
*4 kW R88M-K4K030H- R88M-K4K030T- R88D-KN50H-ECT
5 kW R88M-K5K030H- R88M-K5K030T- R88D-KN50H-ECT
3-phase 400 V *750 W R88M-K75030F- R88M-K75030C- R88D-KN10F-ECT
*1 kW R88M-K1K030F- R88M-K1K030C- R88D-KN15F-ECT
1.5 kW R88M-K1K530F- R88M-K1K530C- R88D-KN15F-ECT
2 kW R88M-K2K030F- R88M-K2K030C- R88D-KN20F-ECT
3 kW R88M-K3K030F- R88M-K3K030C- R88D-KN30F-ECT
*4 kW R88M-K4K030F- R88M-K4K030C- R88D-KN50F-ECT
5 kW R88M-K5K030F- R88M-K5K030C- R88D-KN50F-ECT
