Onkyo A-9377 Service Manual

2/4 PAGE
EXPLODED
A08 FRAME A-9377S (ALL) SIV-00251 ABS HF380 A1/FRONT 1 3217212051100S (S)
EXPLODED
A09 BUTTON A-9377B (CPP) ABS UV COATING A4 / POWER 1 5097213841000S (B)
EXPLODED
A09 BUTTON
A-9377S (CPP) ABS SIV-00251증착+UV COATING/POWER
1 5097213841100S (S)
EXPLODED
A10 BRACKET SR7200/U2B(MARANTZ) SECC 1.0t /POWER 1 4010210876000S
EXPLODED
A13 LENS A9377/CPP(ONKYO) ACRYL MILKY A4/TONE 1 3710210823000S
EXPLODED
A14 LENS A9377/CPP ACRYL MILKY A4/INPUT 1 3710210813000S
EXPLODED
A18 CABINET A-9377B (ALL) BLK-00230 SECC t0.8 SPRAY A2/TOP 1 3007211426000S (B)
EXPLODED
A18 CABINET A-9377S (ALL) SIV-00259 SECC t0.8 SPRAY A2/TOP 1 3007211426010S (S)
EXPLODED
A19 LEG AS 4 27175425
EXPLODED
A20 CHASSIS A9377/CPP(ONKYO) SECC 1.2t A1/MAIN 1 3200212866000S NSP
EXPLODED
A21 FASTENER () BUTTON SUPPORT DABS-16R 4 4420040243010S
EXPLODED
A22 SUPPORTER R871G(DOM) DONG-A DABS-10R(L) 10mm / PCB 3 4070210344000S
EXPLODED
A23 CUSHION
SX315KUCXCN(PIONEER) EVA BKΦ10XΦ5X8t/TRANS SCREW
2 4050211205000S
EXPLODED
A24 POWER TRANS A-9377(CPP)/MAIN 230V/50HZ 96*56 1 8200960560200S <CPP>
EXPLODED
A24 POWER TRANS A-9377(CWT)/MAIN 220V-240V/50HZ-60HZ 96*56 1 8200960560210S <CWT>
EXPLODED
A27 HEAT SINK A9377/CPP AL 6063 EXT A3/MAIN 1 2120211458000S NSP
EXPLODED
A28 BRACKET A9377/CPP SECC t1 A4/HEATSINK 1 4010214096000S
EXPLODED
A29 BRACKET AVCS7000S(DENON) SECC 1.0t A4/PCB 2 4010212356000S
EXPLODED
A31 CHASSIS
A-9377 (CPP) SECC 0.8t Silk 1도 A2 / BACK
1 3207212856000S <CPP>
EXPLODED
A31 CHASSIS
A-9377 (CWT) SECC 0.8t Silk 1도 A2 / BACK
1 3207212856100S <CWT>
EXPLODED
A32 SOCKET,POWER AC AC INLET VAC18S 1 G430000180010S
EXPLODED
A33 TERMINAL S4011062KN 1 3790000090000S
EXPLODED
A34 SUPPORTER UPAF07 ABS BK/PCB 1 4070001601010S
EXPLODED
A35 CUSHION
A9377 CR BK 난연 10t*24*19/PCB
1 4050212595000S
EXPLODED
A36 CUSHION A9377 RUBBER 50*20*t2.5 A4/SIDE 2 4050212545000S

Onkyo A-9377 Specifications

General

Package depth	549 mm
Package width	428 mm
Package height	258 mm
Dimensions (WxDxH)	435 x 15 x 348 mm
Power requirements	AC 220-230 V, 50/60 Hz
Impedance	4 Ω
Frequency range	10 - 70000 Hz
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Silver
Package weight	10700 g
Power consumption (typical)	286 W

Weight and Dimensions

Weight	8800 g
